RCK-310MA – 3U Rackmount Chassis
3U Rackmount chassis for ATX motherboard, (2) 5.25" and (1) 3.5" external drives and (7) 3.5" internal drives, (1) 60mm Fan. 400W ATX power supply
- 3U 19″ Rackmount Standard Chassis
- Heavy duty Steel, Black
- Supports ATX motherboard
- (2) 5.25″ external, (1) 3.5″ external, and (7) 3.5″ internal Drive Bays
- (2) 2.0 USB ports
- (1) 60mm & (1) 80mm ball-bearing fan with space for one additional fan
- Dual Lockable Front Doors and Replaceable Air Filters
- Fan monitor circuit board
- Supports ATX Power Supply
Description
RCK-310MA – 3U Rackmount Chassis
| Board Support | ATX Motherboard |
|---|---|
| Expansion Slots | 7-Slots for full size add-on cards |
| Drive Bays | (2) 5.25″ and (1) 3.5″ external drives and (7) 3.5″ internal drives |
| Front Panel | (2) USB 2.0 Ports on front panel On/Off Switch and Reset Switch, LED for Power ON/OFF, HDD, Fan & Alarm |
| Power Supply | Supports ATX power supply |
| Cooling | (1) 6cm and (1) 8cm Fans on rear panel, and environmental monitoring board (1) extra space for additional 6cm fan |
| Dimensions | 427 (W) x 480 (D) x 132.6 (H)mm; 16.8 (W) x 18.9 (D) x 5.2 (H) inches |
| Net/Gross Weight | 10kg/13.5kg |
