RCK-204M2 – 2U Rackmount Chassis
2U Rackmount chassis for ATX motherboard, (1) 5.25", (1) 3.5" FDD, (2) 3.5" HDD. (2) 80mm Fans, PCIe & PCI riser card, up to 2U 500W Single or 2U 380W Redundant Power supply
- 2U 19″ EIA RS-310C Standard Chassis
- Heavy-duty Steel with Ni plating
- Supports ATX Motherboard (12″ x 9.6″)
- Lockable Front Door and Replaceable Air Filter
- PS/2 connector on front panel
- (2) 80,mm Ball-bearing Fans
- Up to 2U 400W Power supply
- (3) 2U Riser Card for Expansion
Description
RCK-204M2 – 2U Rackmount Chassis
| Board Support | ATX Motherboard |
|---|---|
| Expansion Slots | PCI-303: (3) 32-bit PCI slot PCIE-303: (2) 32-bit PCI slot, (1) PCIe x16 slot PCIE-303A:(1) 32-bit PCI slot, (1) PCIe x16 slot and (1) PCIe x 1 slot |
| Drive Bays | (1) 5.25″ and (1) 3.5″ external drives and (2) 3.5″ internal drives |
| Front Panel | One PS/2 connector and two USB ports Power On/Off Switch and Reset Switch, Power On/Off LED and HDD LED |
| Power Supply | Supports 2U Power supply |
| Cooling | (2) 8 cm ball bearing fans and replaceable air filter |
| Dimensions | 434 (W) x 450 (D) x 88 (H) mm; 17.1 (W) x 17.7 (D) x 3.5 (H) inches |
| Gross Weight | 9.4kg |
