RCK-203BA – 2U Rackmount Chassis
2U Rackmount chassis for Single Board Computer, Black with (1) 5.25" Drive Bays, (1) 3.5" Drive Bay, (1) 3.5" Internal Drive Bay, 4 PCI slot. PICMG 1.0 or PICMG 1.3 SHB Backplane, (2) 60mm Fans, supports PS/2 size power supply
- 2U 19″ Rackmount Standard Chassis
- Heavy duty Ni-plated steel, Black
- Supports PICMG 1.0 Backplane with (4) PCI slots
- Supports PICMG 1.3 Backplane with (2) PCIe x1, (1) PCIe x16 and (1) PCI slots
- (1) 5.25″ (1) 3.5″ external and (1) 3.5″ Internal Drive Bay
- (2) 2.0 USB ports
- (2) 60mm ball-bearing fans with space for one additional fan
- Dual Lockable Front Doors and Replaceable Air Filters
- Optional 400W PS/2 ATX Power Supply
Description
RCK-203BA – 2U Rackmount Chassis
| Board Support | Full size Single Board Computer |
|---|---|
| Expansion Slots | 4-slots PICMG 1.0/1.3 butterfly backplane |
| Drive Bays | 5.25″ and (1) 3.5″ external drives and (1) 3.5″ internal drives |
| Front Panel | (2) USB 2.0 Ports on front panel On/Off Switch and Reset Switch, Power On/Off LED and HDD LED |
| Power Supply | Supports PS/2 size power supply |
| Cooling | (2) 6 cm and one extra space for additional fan |
| Dimensions | 427 (W) x 480 (D) x 88.2 (H) mm; 16.8 (W) x 18.9 (D) x 3.5 (H) inches |
| Net/Gross Weight | 8.4Kg/12kg |
