RCK-202B – 2U Rackmount Chassis
2U Rackmount chassis for Single Board Computer, (2) 5.25" bays or (3) HDD mobile rack, PICMG 1.0/1.3 backplane and PS/2 80PLUS ATX or Mini-Redundant power supply
- 2U 19″ Rackmount Standard Chassis
- Heavy duty Ni-plated steel, Black
- Supports PICMG1.0/1.3 Backplane with optional 2/4 PCI or 5 PCIe slots for Expansion
- Supports (2) 5.25″ or (3) 3.5″ internal Drive Bays (optional)”
- Supports HDD mobile rack
- Lockable Front Door and Replaceable Air Filter
- (2) 80mm Replaceable High-speed Ball Bearing Fans for Better Ventilation
- 400W 80PLUS or Mini-Redundant Power Supply
Description
RCK-202B – 2U Rackmount Chassis
| Board Support | Full size Single Board Computer |
|---|---|
| Expansion Slots | PICMG 1.0/1.3 butterfly backplane (see ordering information and Recommended Configuration) |
| Drive Bays | (2) 5.25″ or (3) 3.5″ internal drives (optional) |
| Front Panel | On/Off Switch and Reset Switch, Power On/Off LED and HDD LED (2) USB 2.0 ports, and PS/2 connector |
| Power Supply | 400W/600W PS/2 ATX power supply (80PLUS optional) 400W/500W/600W Hot Swap Mini-Redundant Power Supply |
| Cooling | (2) 80mm ball bearing fans and replaceable air filter |
| Dimensions | 434 (W) x 450 (D) x 88 (H) mm; 17 (W) x 17.7 (D) x 3.5 (H) inches |
| Net/Gross Weight | 7.6Kg/11.3kg |
